Product Overview
Camera Specs
HDTV 720p, dynamic (VGA – HDTV)
Motion sensor with 4D technology • Distance up to 10 m adjustable via App (interval: 1 m)
High-end ultra wide-angle hemispheric lens 180° (D), 140° (H), 100° (V), straightened, IR capable
Night-vision capable, light sensor, automatic IR-cut filter, 12 Infrared LEDs (850 nm)
Camera range is 1 - 10 m (3.3 - 32.9 ft), depends on environment, configurable in 1 m (3.3 ft) steps
Configuration Options
• Range (1 - 10 m / 3.3 - 32.9 ft) • Movement direction (coming, leaving, both) • Individual events (e.g. switch a relay, push notification, SIP call [audio/video], HTTP(s) notification) • Individual schedules
Audio
Components consist of speaker and microphone with noise reduction and echo cancellation (ANR, AEC)
Audio streaming two-way, full duplex
Fingerprint Reader Features
• Touch sensor • Configurable via App or web-based dashboard • Status LED (RGB) • Fully integrated into DoorBird IP Video Door Stations • 1,000 times more secure than a 4-digit keypad PIN code • Manipulation prevention system • Event history with time stamp • No more misplaced, forgotten, lost or stolen keys possible • No unauthorized use of PIN codes or RFID key fobs possible, a fingerprint is unique per person • Personalized time frames and actions • Supported number of fingerprints (template storage): 50 • Compatible with DoorBird IP Video Door Stations of the D21x and D11x series
Fingerprint Reader Security Features
A fingerprint can a be deleted remotely in real-time in case the access has to be revoked. You can also define individually per fingerprint which action should be executed, e.g. trigger relay 1 or relay 2, trigger an IP I/O door controller, call a HTTP(s) URL, arm or disarm an alarm system, open a smart lock or trigger a building automation system event. The reader does not store any fingerprint images. It stores only one template per fingerprint in form of a mathematically calculated hash value. Biometric features are not transmitted to the DoorBird Door Station, the app or the cloud. In addition, the fingerprint reader has a locking mechanism which prevents attempts at manipulation, temporarily locking the system after 5 unauthorized access attempts.
System Requirements
Mobile device: Newest iOS on iPhone/iPad, newest Android on Smartphone/Tablet Internet: High-Speed Landline Broadband Internet connection: DSL, cable or fiber optic, no socks or proxy server Network: Ethernet Network, with DHCP
Parts included
1x Main Electrical Unit 1x Front panel 1x Nameplate for 1 call button, stainless steel, bell symbol 1x RFID key fob 1x Screwdriver 1x Quickstart guide with Digital Passport 1x Installation manual 1x Small parts
Additional Features
IP65 rated
Choose color & material for custom look
Geofencing allows for automatic door and gate opening when returning home
Free visitor history • Store still images for free, optional video recording available
Automatic door buzzer for use in medical offices and office environments
Call button with backlit nameplate
Proposition 65 Warning for California Residents
